00.15
21 Clutch
Connection Nm Nm
Clutch housing Joint torque 40 40
oil screw threads lightly
Additional wrench angle 32°
Housing cover 18 18
Locknut on release lever 22 22
23 Gearbox
Oil filler plug 23 23
Oil drain plug 23 23
Gearbox cover to gearbox housing 9 9
Screw for neutral detent 13 13
clean thread + Loctite 243
Oil guide plate at gearbox housing 9 9
clean thread + Loctite 573, also apply Loctite 573
to sealing face between oil baffle plate and gear-
box housing
Gearbox to engine block 22 22
Clutch lever to gearbox housing 18 18
Selector lever to selector shaft 9 9
Pedal to footrest plate 35 35
Model R 850/1100 GS R850/1100R
