00.16
31 Front fork
Connection Nm Nm
Screw connection between fixed tube and
fork bridge
45 (free from oil and
grease)
45 (free from oil and
grease)
Control arm to ball joint 130 130
clean thread + Loctite 2701
Threaded journal to frame 130 130
clean threads + Loctite 243
Ball joint to fork slider tube bridge 230 230
Slider tube bridge to slider tube 22 22
clean threads
+ Loctite 243
Screw plug to fixed fork tube press fit, do not release!
Clamping screws, quick-release axle 22 22
Control arm to engine right 73 73
Screw cap left 42 42
apply light coat of Never Seez to thread
Spring strut to frame 47 47
Spring strut to control arm 50
10.9 screw
50
10.9 screw
Steering damper to fork slider bridge mount – 20
clean thread
+ Loctite 2701
Steering damper mount to fork slider bridge – 9
clean thread
+ Loctite 2701
Steering damper to leading link pivot mount – 20
clean thread
+ Loctite 2701
Steering damper pivot mount at leading link – 20
Joint head against locknut – 20
Model R 850/1100 GS R850/1100R
