32 Steering
Connection Nm Nm
Handlebar to fork bridge 21 21
Twistgrip to handlebar 7 7
Handlebar weight to fixed handlebar 20 20
33 Rear wheel drive
Oil drain plug 23 23
Oil filler plug 23 23
Threaded ring 118 (Hylomar SQ 32 M) 118 (Hylomar SQ 32 M)
Hexagon nut, input bevel gear 200 200
clean thread + Loctite 273
Housing cover 35 35
Fixed bearing journal
Swinging arm at gearbox
Swinging arm at rear wheel drive
150 150
clean thread + Loctite 2701
Free bearing journal
Swinging arm to gearbox/
Swinging arm to rear wheel drive
77
clean thread + Loctite 2701
Locknut on free bearing journal 105 105
clean thread + Loctite 2701
Strut at rear wheel drive / gearbox 43 43
(load motorcycle with approx. 85 kg and tighten
loose strut)
Spring strut to rear frame / rear swinging arm 50
10.9 screw
50
10.9 screw
Hydraulic spring adjuster at footrest plat 22 –
Model R 850/1100 GS R850/1100R
