00.18
34 Brakes
Connection Nm Nm
Brake caliper to slider tube 40 40
Brake caliper to rear wheel drive 40 40
Brake disc to front wheel
Cast wheel
Spoked whee
–
24
21
24
clean thread + Loctite 243
Brake disc to rear wheel drive 21 21
clean thread + Loctite 273
Brake disc to rear wheel 21 21
clean thread + Loctite 243
Brake hose to brake caliper, front/rear 15 15
Brake hose to fitting 15 15
Brake hose to flow distributor 15 15
Flow distributor to frame 9 9
Flow distributor to slider tube bridge 9 –
Flow distributor to holder/slider tube – 9
Bleed screw on front brake caliper 7 7
Bleed screw on rear brake caliper 4 4
Master cylinder to footrest plate 9 9
Brake pedal to footrest plate 37 37
Handbrake lever pivot pinl 8 8
(the Tuflok blue thread retaining agent can be
slackened off and tightened several times if nec-
essary)
ABS sensor 4 (handtight) 4 (handtight)
ABS unit to holder
M6 screw 9 9
M6 screw (Torx) 5 5
Brake line to ABS unit 15 15
Bleed screw to ABS unit 9 9
Model R 850/1100 GS R850/1100R
