00.19
36 Wheels and tyres
Connection Nm Nm
Clamping screws, quick-release axle 22 22
Screw connection, quick-release axle 30 30
Screw on wheel nuts handtight, then tighten
crosswise:
Initial tightening
Final tightening
50
105
50
105
46 Frame
Rear frame to gearbox/engine 47 47
1. Screw connection on right of gearbox
2. at right of engine
3. at left of engine
4. at left of gearbox
Footrest plate to gearbox 22 22
Frame to engine 82 82
Struts to frame 47
8.8 screw
47
8.8 screw
58
10.9 screw
58
10.9 screw
Struts to engine 58 58
Guard hoop to cylinder head 20 20
Side stand to pivot mount 42 42
clean thread + Loctite 2701
Center stand to carrier plate 21 21
clean thread + Loctite 2701
Carrier plate for center stand to engine block
M12 screw 72 72
clean thread + Loctite 2701
M 8 screw (countersunk) 21 21
clean thread + Loctite 2701
Footrest plate to rear frame
M 8 screw 21 21
Fairing support bracket to frame 20 –
Model R 850/1100 GS R850/1100R
