36.4
Technical Data R 1100 RT
Rim size
front 3,50 x 17 MT H 2
rear 4,50 x 18 MT H 2
Max. vertical/lateral runout Cast wheel
front mm (in) 0.5 (0.0197)
rear mm (in) 0.3 (0.0118)
Tyre size Cast wheel
front 120/70 ZR 17 Tubeless
rear 160/60 ZR 18 Tubeless
Tyre pressure (cold)
Solo front bar (psi) 2.2 (31.91)
rear bar (psi) 2.5 (36.26)
With pillion passenger
front bar (psi) 2.5 (36.26)
rear bar (psi) 2.7 (39.16)
With pillion passenger and luggage
front bar (psi) 2.5 (36.25)
rear bar (psi) 2.9 (42.06)
