36.5
Technical Data R 850 GS R 1100 GS
Rim size
front 2,50 x 19 MT H 2 2,50 x 19 MT H 2
rear 4,00 x 17 MT H 2 4,00 x 17 MT H 2
Max. vertical/lateral runout Spoked wheel Spoked wheel
front mm (in) 1.3 (0.0512) 1.3 (0.0512)
rear mm (in) 1.3 (0.0512) 1.3 (0.0512)
Tyre size Spoked wheel Spoked wheel
front 110/80 R 19 59 H
Tubeless
110/80 R 19 59 H
Tubeless
rear 150/70 R 17 69 H
Tubeless
150/70 R 17 69 H
Tubeless
Tyre pressure (cold)
Solo front bar (psi) 2.2 (31.91) 2.2 (31.91)
rear bar (psi) 2.5 (36.26) 2.5 (36.26)
With pillion passenger
front bar (psi) 2.5 (36.26) 2.5 (36.26)
rear bar (psi) 2.7 (39.16) 2.7 (39.16)
With pillion passenger and luggage
front bar (psi) 2.5 (36.25) 2.5 (36.25)
rear bar (psi) 2.9 (42.06) 2.9 (42.06)
