36.6
Technical Data R 850 R R 1100 R
Rim size Cast wheel Cast wheel
front 3,50 x 17 MT H 2 3,50 x 17 MT H 2
rear 4,50 x 18 MT H 2 4,50 x 18 MT H 2
Spoked wheel Spoked wheel
front 2,50 x 18 MT H 2 2,50 x 18 MT H 2
rear 4,00 x 17 MT H 2 4,00 x 17 MT H 2
Max. vertical/lateral runout Cast wheel Cast wheel
front mm (in) 0.5 (0.0197) 0.5 (0.0197)
rear mm (in) 0.3 (0.0118) 0.3 (0.0118)
Spoked wheel Spoked wheel
front mm (in) 1.3 (0.0512) 1.3 (0.0512)
rear mm (in) 1.3 (0.0512) 1.3 (0.0512)
Tyre size Cast wheel Cast wheel
front 120/70 ZR 17 Tubeless 120/70 ZR 17 Tubeless
rear 160/60 ZR 18 Tubeless 160/60 ZR 18 Tubeless
Spoked wheel Spoked wheel
front 110/80 ZR 18 Tubeless 110/80 ZR 18 Tubeless
rear 150/70 ZR 17 Tubeless 150/70 ZR 17 Tubeless
Tyre pressure (cold)
Solo front bar (psi) 2.2 (31.91) 2.2 (31.91)
rear bar (psi) 2.5 (36.26) 2.5 (36.26)
With pillion passenger
front bar (psi) 2.5 (36.26) 2.5 (36.26)
rear bar (psi) 2.7 (39.16) 2.7 (39.16)
With pillion passenger and luggage
front bar (psi) 2.5 (36.25) 2.5 (36.25)
rear bar (psi) 2.9 (42.06) 2.9 (42.06)
