00.40

With cable junction block

•

Push back the protective rubber cap (1) at the

throttle and choke cables.

•

Turn adjusting screw (2) at the throttle and choke

cables to adjust play.

Choke cable play:................. app. 1 mm (0.039 in)

Throttle cable play:............... app. 1 mm (0.039 in)

•

Turn adjusting screws at the left and right throt-

tles to adjust play.

Throttle cable play:............. app. 2 mm (0.0787 in)

•

Connect the BMW Synchrotester,

BMW No. 13 0 800, to the vacuum

bores of the throttles..

•

Ride the motorcycle until the engine is warm,

or alternatively allow it to warm up at a

standstill for approx. 10 minutes.

e Caution:

Engine must not run for more than 20 minutes when

motorcycle is not moving.

Oil temperature: ...............................at least 90 °C

(FID: at least 5 bars)

•

Switch on the Synchrotester and select the bar

chart with maximum resolution.

L Note:

If the differences between the individual

columns are very large (greater than 5 mm), switch

to graph display and compare the cylinders; carry

out fault diagnosis if necessary.

a See BMW Synchrotester diagnosis instructions.

RT000080

RT000070
