11.45
•
[ABS] unit - remove.
L Note:
Retain brake lines with cable straps.
e Caution:
Always follow the instructions in the repair manua
a See Group 34,Removing and installing
ABS unit.
•
[ABS] Detach brake pipes at gearbox.
•
[RT] Detach brake master cylinder.
RS340010
RS110530
