ioLogik E2200 Series Using the Web Console
5-12
Sensor Type Degree Count
Ni1000, 0.00618 -60 to 180°C -600 to 1800
Ni120, 0.00672 -80 to 260°C -800 to 2600
Channels 6 through 11 are virtual channels. You can click on a virtual channel to configure whether it will return
current averages or deviations for the specified physical channels (RTD-00 through RTD-05).
TC Channels
On the TC Channels page, you can view the status of all TC channels, which includes both physical and virtual
channels. You can click the Channel Name to enter settings page on which can set the Alias Name.
You can click on each channel to enable or disable it, or to configure the TC input mode. When a channel has
been disabled, the sample rate of the remaining channels will be increased automatically.
The following table is a list of supported sensor types and ranges.
Type Temperature Range Count Range
J 0°C
to 750°C 0
to 7,500
K -200°C
to 1250°C -2,000
to 12,500
T -200°C
to 350°C -2,000
to 3,500
E -200°C
to 900°C -2,000
to 9,000
R -50°C
to 1600°C -500
to 16,000
S -50°C
to 1760°C -500
to 17,600
B 600°C
to 1700°C 6,000
to 17,000
N -200°C
to 1300°C -2,000
to 13,000
Voltage: 78.126 mV - 78.126 mV
to 78.126 mV -781,260
to 781,260
Voltage: 39.062 mV - 39.062 mV
to 39.062 mV -390,620
to 390,620
Voltage: 19.532 mV - 19.532 mV
to 19.532 mV -195,320
to 195,320
