ioLogik E2200 Series Modbus/TCP Address Mappings
I-82
Reference Address Data Type Description
00017 0x0010 1 bit CH0 TC Reset Maximum Value
00018 0x0011 1 bit CH1 TC Reset Maximum Value
00019 0x0012 1 bit CH2 TC Reset Maximum Value
00020 0x0013 1 bit CH3 TC Reset Maximum Value
00021 0x0014 1 bit CH4 TC Reset Maximum Value
00022 0x0015 1 bit CH5 TC Reset Maximum Value
00023 0x0016 1 bit CH6 TC Reset Maximum Value
00024 0x0017 1 bit CH7 TC Reset Maximum Value
00025 0x0018 1 bit Virtual CH8 TC Reset Maximum Value
00026 0x0019 1 bit Virtual CH9 TC Reset Maximum Value
00027 0x001A 1 bit Virtual CH10 TC Reset Maximum Value
00028 0x001B 1 bit Virtual CH11 TC Reset Maximum Value
00029 0x001C 1 bit Virtual CH12 TC Reset Maximum Value
00030 0x001D 1 bit Virtual CH13 TC Reset Maximum Value
00031 0x001E 1 bit Virtual CH14 TC Reset Maximum Value
00032 0x001F 1 bit Virtual CH15 TC Reset Maximum Value
00033 0x0020 1 bit CH0 TC Enable
<RW> 0=Disable, 1=Enable
00034 0x0021 1 bit CH1 TC Enable
00035 0x0022 1 bit CH2 TC Enable
00036 0x0023 1 bit CH3 TC Enable
00037 0x0024 1 bit CH4 TC Enable
00038 0x0025 1 bit CH5 TC Enable
00039 0x0026 1 bit CH6 TC Enable
00040 0x0027 1 bit CH7 TC Enable
00041 0x0028 1 bit CH0 DO Status
<RW> 0=OFF, 1=ON
00042 0x0029 1 bit CH1 DO Status
00043 0x002A 1 bit CH2 DO Status
00044 0x002B 1 bit CH3 DO Status
00045 0x002C 1 bit CH0 DO Power-On Status
<RW> 0=OFF, 1=ON
00046 0x002D 1 bit CH1 DO Power-On Status
00047 0x002E 1 bit CH2 DO Power-On Status
00048 0x002F 1 bit CH3 DO Power-On Status
00049 0x0030 1 bit CH0 DO Safe Status
<RW> 0=OFF, 1=ON
00050 0x0031 1 bit CH1 DO Safe Status
00051 0x0032 1 bit CH2 DO Safe Status
00052 0x0033 1 bit CH3 DO Safe Status
00053 0x0034 1 bit CH0 DO Pulse Output Status
<RW> 0=Stop, 1=Start
00054 0x0035 1 bit CH1 DO Pulse Output Status
00055 0x0036 1 bit CH2 DO Pulse Output Status
00056 0x0037 1 bit CH3 DO Pulse Output Status
00057 0x0038 1 bit CH0 DO Power-On Pulse Output Status
<RW> 0=Stop, 1=Start
00058 0x0039 1 bit CH1 DO Power-On Pulse Output Status
00059 0x003A 1 bit CH2 DO Power-On Pulse Output Status
00060 0x003B 1 bit CH3 DO Power-On Pulse Output Status
00061 0x003C 1 bit CH0 DO Safe Mode Pulse Output Status
<RW> 0=Stop, 1=Start
