ioLogik E2200 Series Modbus/TCP Address Mappings
I-14
Reference Address Data Type Description
40335 0x014E 1 word CH6 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40336 0x014F 1 word CH7 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40337 0x0150 1 word CH8 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40338 0x0151 1 word CH9 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40339 0x0152 1 word CH10 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40340 0x0153 1 word CH11 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow stat
1 : Return illegal data value (0x03)
40341 0x0154 1 word
CH0 DI Counter Trigger，0=Low to High, 1=High to Low
40342 0x0155 1 word
CH1 DI Counter Trigger，0=Low to High, 1=High to Low
40343 0x0156 1 word
CH2 DI Counter Trigger
，
0=Low to High, 1=High to Low
40344 0x0157 1 word
CH3 DI Counter Trigger，0=Low to High, 1=High to Low
40345 0x0158 1 word
CH4 DI Counter Trigger，0=Low to High, 1=High to Low
40346 0x0159 1 word
CH5 DI Counter Trigger，0=Low to High, 1=High to Low
40347 0x015A 1 word
CH6 DI Counter Trigger
，
0=Low to High, 1=High to Low
40348 0x015B 1 word
CH7 DI Counter Trigger，0=Low to High, 1=High to Low
40349 0x015C 1 word
CH8 DI Counter Trigger，0=Low to High, 1=High to Low
40350 0x015D 1 word
CH9 DI Counter Trigger
，
0=Low to High, 1=High to Low
40351 0x015E 1 word
CH10 DI Counter Trigger，0=Low to High, 1=High to Low
40352 0x015F 1 word
CH11 DI Counter Trigger，0=Low to High, 1=High to Low
40353 0x0160 1 word CH0 DI PowerOn Counter Operate Status 0: Stop 1: Start
40354 0x0161 1 word CH1 DI PowerOn Counter Operate Status 0: Stop 1: Start
40355 0x0162 1 word CH2 DI PowerOn Counter Operate Status 0: Stop 1: Start
40356 0x0163 1 word CH3 DI PowerOn Counter Operate Status 0: Stop 1: Start
40357 0x0164 1 word CH4 DI PowerOn Counter Operate Status 0: Stop 1: Start
40358 0x0165 1 word CH5 DI PowerOn Counter Operate Status 0: Stop 1: Start
40359 0x0166 1 word CH6 DI PowerOn Counter Operate Status 0: Stop 1: Start
40360 0x0167 1 word CH7 DI PowerOn Counter Operate Status 0: Stop 1: Start
40361 0x0168 1 word CH8 DI PowerOn Counter Operate Status 0: Stop 1: Start
40362 0x0169 1 word CH9 DI PowerOn Counter Operate Status 0: Stop 1: Start
40363 0x016A 1 word CH10 DI PowerOn Counter Operate Status 0: Stop 1: Start
40364 0x016B 1 word CH11 DI PowerOn Counter Operate Status 0: Stop 1: Start
40365 0x016C 1 word CH0 DI Safe Mode Counter Operate Status 0: Stop 1: Start
40366 0x016D 1 word CH1 DI Safe Mode Counter Operate Status 0: Stop 1: Start
40367 0x016E 1 word CH2 DI Safe Mode Counter Operate Status 0: Stop 1: Start
40368 0x016F 1 word CH3 DI Safe Mode Counter Operate Status 0: Stop 1: Start
