ioLogik E2200 Series Modbus/TCP Address Mappings
I-35
Reference Address Data Type Description
40224 0x00DF 1 word CH7 DI safe mode counter operate status
0: stop 1: start
40225 0x00E0 1 word CH8 DI safe mode counter operate status
0: stop 1: start
40226 0x00E1 1 word CH9 DI safe mode counter operate status
0: stop 1: start
40227 0x00E2 1 word CH10 DI safe mode counter operate status
0: stop 1: start
40228 0x00E3 1 word CH11 DI safe mode counter operate status
0: stop 1: start
40229 0x00E4 1 word CH0 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40230 0x00E5 1 word CH1 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40231 0x00E6 1 word CH2 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40232 0x00E7 1 word CH3 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40233 0x00E8 1 word CH4 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40234 0x00E9 1 word CH5 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40235 0x00EA 1 word CH6 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40236 0x00EB 1 word CH7 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40237 0x00EC 1 word CH8 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40238 0x00ED 1 word CH9 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40239 0x00EE 1 word CH10 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40240 0x00EF 1 word CH11 DI set channel
Power-off storage enable ON/OFF
1: on 0: off
40241 0x00F0 1 word DIO 0
1: output DO mode
0: input DI mode
40242 0x00F1 1 word DIO 1
1: output DO mode
0: input DI mode
