ioLogik E2200 Series Modbus/TCP Address Mappings
I-51
Reference Address Data Type Description
40010 0x0009 1 word CH1 AO power-on range
0: 0 to 10 VDC
1: 4 to 20 mA
Other: return illegal data value
40011 0x000A 1 word CH0 AO safe range
0: 0 to 10 VDC
1: 4 to 20 mA
Other: return illegal data value
40012 0x000B 1 word CH1 AO safe range
0: 0 to 10 VDC
1: 4 to 20 mA
Other: return illegal data value
40013 0x000C 1 word CH0 AI range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40014 0x000D 1 word CH1 AI range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40015 0x000E 1 word CH2 AI range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40016 0x000F 1 word CH3 AI range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40017 0x0010 1 word CH4 AI range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
