ioLogik E2200 Series Modbus/TCP Address Mappings
I-16
Reference Address Data Type Description
00013 0x000C 1 bit CH0 DO power-on value
0: off 1: on
00014 0x000D 1 bit CH1 DO power-on value
0: off 1: on
00015 0x000E 1 bit CH2 DO power-on value
0: off 1: on
00016 0x000F 1 bit CH3 DO power-on value
0: off 1: on
00017 0x0010 1 bit CH4 DO power-on value
0: off 1: on
00018 0x0011 1 bit CH5 DO power-on value
0: off 1: on
00019 0x0012 1 bit CH6 DO power-on value
0: off 1: on
00020 0x0013 1 bit CH7 DO power-on value
0: off 1: on
00021 0x0014 1 bit CH8 DO power-on value
0: off 1: on
00022 0x0015 1 bit CH9 DO power-on value
0: off 1: on
00023 0x0016 1 bit CH10 DO power-on value
0: off 1: on
00024 0x0017 1 bit CH11 DO power-on value
0: off 1: on
00025 0x0018 1 bit CH0 DO safe value
0: off 1: on
00026 0x0019 1 bit CH1 DO safe value
0: off 1: on
00027 0x001A 1 bit CH2 DO safe value
0: off 1: on
00028 0x001B 1 bit CH3 DO safe value
0: off 1: on
00029 0x001C 1 bit CH4 DO safe value
0: off 1: on
00030 0x001D 1 bit CH5 DO safe value
0: off 1: on
00031 0x001E 1 bit CH6 DO safe value
0: off 1: on
00032 0x001F 1 bit CH7 DO safe value
0: off 1: on
00033 0x0020 1 bit CH8 DO safe value
0: off 1: on
00034 0x0021 1 bit CH9 DO safe value
0: off 1: on
00035 0x0022 1 bit CH10 DO safe value
0: off 1: on
00036 0x0023 1 bit CH11 DO safe value
0: off 1: on
00037 0x0024 1 bit CH0 DO pulse operate status
0: off 1: on
00038 0x0025 1 bit CH1 DO pulse operate status
0: off 1: on
