ioLogik E2200 Series CGI Commands
G-20
Commands to get RTD Virtual Channel
information
Commands to get RTD Virtual Channel
information
RtdEnable_06
(0:Disable, 1:Enable)
RtdEnable_07
(0:Disable, 1:Enable)
RtdStype_06
(20:Average – For Virtual Channel only, 21: Deviation
– For Virtual Channel Only)
RtdStype_07
(20:Average – For Virtual Channel only, 21: Deviation
– For Virtual Channel Only)
RtdUtype_06
(Unit Types. 0:°C, 1:°F, 2:Ω)
RtdUtype_07
(Unit Types. 0:°C, 1:°F, 2:Ω)
RtdStatus_06 RtdStatus_07
RtdEnable_08
(0:Disable, 1:Enable)
RtdEnable_09
(0:Disable, 1:Enable)
RtdStype_08
(20:Average – For Virtual Channel only, 21: Deviation
– For Virtual Channel Only)
RtdStype_09
(20:Average – For Virtual Channel only, 21: Deviation
– For Virtual Channel Only)
RtdUtype_08
(Unit Types. 0:°C, 1:°F, 2:Ω)
RtdUtype_09
(Unit Types. 0:°C, 1:°F, 2:Ω)
RtdStatus_08 RtdStatus_09
RtdEnable_10
(0:Disable, 1:Enable)
RtdEnable_11
(0:Disable, 1:Enable)
RtdStype_10
(20:Average – For Virtual Channel only, 21: Deviation
– For Virtual Channel Only)
RtdStype_11
(20:Average – For Virtual Channel only, 21: Deviation
– For Virtual Channel Only)
RtdUtype_10
(Unit Types. 0:°C, 1:°F, 2:Ω)
RtdUtype_11
(Unit Types. 0:°C, 1:°F, 2:Ω)
RtdStatus_10 RtdStatus_11
Commands to get DO information Commands to get DO information
DOMode_00
(0:DO, 1:PULSE OUTPUT)
DOMode_01
(0:DO, 1:PULSE OUTPUT)
DOStatus_00
(0:OFF, 1:ON)
DOStatus_01
(0:OFF, 1:ON)
DOLowWidth_00 DOLowWidth_01
DOHighWidth_00 DOHighWidth_01
DOPulseStart_00
(0:STOP, 1:START)
DOPulseStart_01
(0:STOP, 1:START)
DOMode_02
(0:DO, 1:PULSE OUTPUT)
DOMode_03
(0:DO, 1:PULSE OUTPUT)
DOStatus_02
(0:OFF, 1:ON)
DOStatus_03
(0:OFF, 1:ON)
DOLowWidth_02 DOLowWidth_03
DOHighWidth_02 DOHighWidth_03
DOPulseStart_02
(0:STOP, 1:START)
DOPulseStart_03
(0:STOP, 1:START)
