ioLogik E2200 Series Modbus/TCP Address Mappings
I-43
Reference Address Data Type Description
40039 0x0026 word CH2 DI Mode 0: DI
1: Count
Others : return Illegal Data Value
40040 0x0027 word CH3 DI Mode 0: DI
1: Count
Others : return Illegal Data Value
40041 0x0028 word CH4 DI Mode 0: DI
1: Count
Others : return Illegal Data Value
40042 0x0029 word CH5 DI Mode 0: DI
1: Count
Others : return Illegal Data Value
40043 0x002A 1 word CH0 DO Value 0: Off 1: On
40044 0x002B 1 word CH1 DO Value 0: Off 1: On
40045 0x002C 1 word CH2 DO Value 0: Off 1: On
40046 0x002D 1 word CH3 DO Value 0: Off 1: On
40047 0x002E 1 word CH4 DO Value 0: Off 1: On
40048 0x002F 1 word CH5 DO Value 0: Off 1: On
40049 0x0030 1 word CH0 DO Power On Value 0: Off 1: On
40050 0x0031 1 word CH1 DO Power On Value 0: Off 1: On
40051 0x0032 1 word CH2 DO Power On Value 0: Off 1: On
40052 0x0033 1 word CH3 DO Power On Value 0: Off 1: On
40053 0x0034 1 word CH4 DO Power On Value 0: Off 1: On
40054 0x0035 1 word CH5 DO Power On Value 0: Off 1: On
40055 0x0036 1 word CH0 DO Safe Mode Value 0:
Off 1: On 2: Hold Last
40056 0x0037 1 word CH1 DO Safe Mode Value 0:
Off 1: On 2: Hold Last
40057 0x0038 1 word CH2 DO Safe Mode Value 0:
Off 1: On 2: Hold Last
40058 0x0039 1 word CH3 DO Safe Mode Value 0:
Off 1: On 2: Hold Last
40059 0x003A 1 word CH4 DO Safe Mode Value 0:
Off 1: On 2: Hold Last
40060 0x003B 1 word CH5 DO Safe Mode Value 0:
Off 1: On 2: Hold Last
40061 0x003C 1 word CH0 DO Pulse Operate Status 0: Stop 1: Start
40062 0x003D 1 word CH1 DO Pulse Operate Status 0: Stop 1: Start
40063 0x003E 1 word CH2 DO Pulse Operate Status 0: Stop 1: Start
40064 0x003F 1 word CH3 DO Pulse Operate Status 0: Stop 1: Start
40065 0x0040 1 word CH4 DO Pulse Operate Status 0: Stop 1: Start
40066 0x0041 1 word CH5 DO Pulse Operate Status 0: Stop 1: Start
40067 0x0042 1 word CH0 DO PowerOn Pulse Operate Status 0: Stop 1: Start
40068 0x0043 1 word CH1 DO PowerOn Pulse Operate Status 0: Stop 1: Start
40069 0x0044 1 word CH2 DO PowerOn Pulse Operate Status 0: Stop 1: Start
40070 0x0045 1 word CH3 DO PowerOn Pulse Operate Status 0: Stop 1: Start
40071 0x0046 1 word CH4 DO PowerOn Pulse Operate Status 0: Stop 1: Start
40072 0x0047 1 word CH5 DO PowerOn Pulse Operate Status 0: Stop 1: Start
40073 0x0048 1 word CH0 DO Safe Mode Pulse Operate Status 0: Stop 1: Start
40074 0x0049 1 word CH1 DO Safe Mode Pulse Operate Status 0: Stop 1: Start
40075 0x004A 1 word CH2 DO Safe Mode Pulse Operate Status 0: Stop 1: Start
40076 0x004B 1 word CH3 DO Safe Mode Pulse Operate Status 0: Stop 1: Start
