ioLogik E2200 Series Initial Setup
2-3
NOTE
The best approach to setting up
a previously configured ioLogik is to reset it to the factory default using the
RESET button
(see Chapter 1). You can then use the ioAdmin utility to configure the ioLogik.
NOTE
If the host computer has multiple network interfaces, be sure to select the correct interface before searching.
