ioLogik E2200 Series CGI Commands
G-22
Commands to set DO channels Commands to set DO Channels
DOMode_00
(0:DO, 1:PULSE OUTPUT)
DOMode_01
(0:DO, 1:PULSE OUTPUT)
DOStatus_00
(0:OFF, 1:ON)
DOStatus_01
(0:OFF, 1:ON)
DOLowWidth_00 DOLowWidth_01
DOHighWidth_00 DOHighWidth_01
DOPulseStart_00
(0:STOP, 1:START)
DOPulseStart_01
(0:STOP, 1:START)
DOMode_02
(0:DO, 1:PULSE OUTPUT)
DOMode_03
(0:DO, 1:PULSE OUTPUT)
DOStatus_02
(0:OFF, 1:ON)
DOStatus_03
(0:OFF, 1:ON)
DOLowWidth_02 DOLowWidth_03
DOHighWidth_02 DOHighWidth_03
DOPulseStart_02
(0:STOP, 1:START)
DOPulseStart_03
(0:STOP, 1:START)
ioLogik E2262
Commands to get system information Commands to get system information
DATE FWR_V
TIME MOD_NAME
IP SN_NUM
LOC MAC_ADDR
DESC
Commands to get TC information Commands to get TC information
TcEnable_00
(0:Disable, 1:Enable)
TcEnable_01
(0:Disable, 1:Enable)
TcStype_00
(0:J, 1:K, 2:T, 3:E, 4:R, 5:S, 6:B, 7:N Type and
8:78.126mV, 9:39.062mV, 10:19.532mV)
TcStype_01
(0:J, 1:K, 2:T, 3:E, 4:R, 5:S, 6:B, 7:N Type and
8:78.126mV, 9:39.062mV, 10:19.532mV)
TcUtype_00
(Unit Types. 0:°C, 1:°F, 2:mV)
TcUtype_01
(Unit Types. 0:°C, 1:°F, 2:mV)
TcStatus_00 TcStatus_01
TcEnable_02
(0:Disable, 1:Enable)
TcEnable_03
(0:Disable, 1:Enable)
TcStype_02
(0:J, 1:K, 2:T, 3:E, 4:R, 5:S, 6:B, 7:N Type and
8:78.126mV, 9:39.062mV, 10:19.532mV)
TcStype_03
(0:J, 1:K, 2:T, 3:E, 4:R, 5:S, 6:B, 7:N Type and
8:78.126mV, 9:39.062mV, 10:19.532mV)
TcUtype_02
(Unit Types. 0:°C, 1:°F, 2:mV)
TcUtype_03
(Unit Types. 0:°C, 1:°F, 2:mV)
TcStatus_02 TcStatus_03
TcEnable_04
(0:Disable, 1:Enable)
TcEnable_05
(0:Disable, 1:Enable)
TcStype_04
(0:J, 1:K, 2:T, 3:E, 4:R, 5:S, 6:B, 7:N Type and
8:78.126mV, 9:39.062mV, 10:19.532mV)
TcStype_05
(0:J, 1:K, 2:T, 3:E, 4:R, 5:S, 6:B, 7:N Type and
8:78.126mV, 9:39.062mV, 10:19.532mV)
TcUtype_04
(Unit Types. 0:°C, 1:°F, 2:mV)
TcUtype_05
(Unit Types. 0:°C, 1:°F, 2:mV)
TcStatus_04 TcStatus_05
