ioLogik E2200 Series Introduction
1-14
TB1 (Power Input & RS-485 Connector)
Pin 1 2 3 4 5 6
Signal V+ V- FG D+ D- SG
(V+: 12 to
36 VDC)
TB2 (Input and Output Terminal)
Refer to the Appendix F.
LED Indicators
LED Light Description
PWR Off System power off
Red System power on
RDY Off System not ready
Green System ready
Red System error
Green Blinking Click & Go running
Green/Red Blinking System in Safe mode
Serial Off Serial port not connected
Red Serial port connected
Blinking Data sending and receiving
Ethernet Off Ethernet port not connected
Amber 10 Mbps connected
Green 100 Mbps connected
Blinking Data sending and receiving
DI Off DI status off
Green DI status on
DO Off DO status off
Red DO status on
DIO Off DI or DO status off
Green DI mode and status on
Amber DO mode and status on
AI Off AI channel disabled
Transmitter not connected when 4-20 mA mode
Green AI channel enabled
RTD Green RTD status on
Red RTD transmitter not connected
TC Green TC status on
Red TC transmitter not connected
DO Power Off External power off or not connected
Red External power on
