ioLogik E2200 Series Modbus/TCP Address Mappings
I-11
Reference Address Data Type Description
40378 0x0179 word Internal Register 01 Initial Value
40379 0x017A word Internal Register 02 Initial Value
40380 0x017B word Internal Register 03 Initial Value
40381 0x017C word Internal Register 04 Initial Value
40382 0x017D word Internal Register 05 Initial Value
40383 0x017E word Internal Register 06 Initial Value
40384 0x017F word Internal Register 07 Initial Value
40385 0x0180 word Internal Register 08 Initial Value
40386 0x0181 word Internal Register 09 Initial Value
40387 0x0182 word Internal Register 10 Initial Value
40388 0x0183 word Internal Register 11 Initial Value
40389 0x0184 word Internal Register 12 Initial Value
40390 0x0185 word Internal Register 13 Initial Value
40391 0x0186 word Internal Register 14 Initial Value
40392 0x0187 word Internal Register 15 Initial Value
40393 0x0188 word Internal Register 16 Initial Value
40394 0x0189 word Internal Register 17 Initial Value
40395 0x018A word Internal Register 18 Initial Value
40396 0x018B word Internal Register 19 Initial Value
40397 0x018C word Internal Register 20 Initial Value
40398 0x018D word Internal Register 21 Initial Value
40399 0x018E word Internal Register 22 Initial Value
40400 0x018F word Internal Register 23 Initial Value
42921 0x0B68 word Internal Register 00 Working Value
42922 0x0B69 word Internal Register 01 Working Value
42923 0x0B6A word Internal Register 02 Working Value
42924 0x0B6B word Internal Register 03 Working Value
42925 0x0B6C word Internal Register 04 Working Value
42926 0x0B6D word Internal Register 05 Working Value
42927 0x0B6E word Internal Register 06 Working Value
42928 0x0B6F word Internal Register 07 Working Value
42929 0x0B70 word Internal Register 08 Working Value
42930 0x0B71 word Internal Register 09 Working Value
42931 0x0B72 word Internal Register 10 Working Value
42932 0x0B73 word Internal Register 11 Working Value
42933 0x0B74 word Internal Register 12 Working Value
42934 0x0B75 word Internal Register 13 Working Value
42935 0x0B76 word Internal Register 14 Working Value
42936 0x0B77 word Internal Register 15 Working Value
42937 0x0B78 word Internal Register 16 Working Value
42938 0x0B79 word Internal Register 17 Working Value
42939 0x0B7A word Internal Register 18 Working Value
42940 0x0B7B word Internal Register 19 Working Value
42941 0x0B7C word Internal Register 20 Working Value
42942 0x0B7D word Internal Register 21 Working Value
42943 0x0B7E word Internal Register 22 Working Value
42944 0x0B7F word Internal Register 23 Working Value
// for Citect SCADA compatibility, I/O data can be WORD accessed as well
40257 0x0100 1 word CH0 DO Value 0: Off 1: On
40258 0x0101 1 word CH1 DO Value 0: Off 1: On
40259 0x0102 1 word CH2 DO Value 0: Off 1: On
40260 0x0103 1 word CH3 DO Value 0: Off 1: On
