ioLogik E2200 Series Modbus/TCP Address Mappings
I-23
Reference Address Data Type Description
00148 0x0093 1 bit CH3 DI set channel
Power-off storage enable on/off
1: on 0: off
00149 0x0094 1 bit CH4 DI set channel
Power-off storage enable on/off
1: on 0: off
00150 0x0095 1 bit CH5 DI set channel
Power-off storage enable on/off
1: on 0: off
00151 0x0096 1 bit CH6 DI set channel
Power-off storage enable on/off
1: on 0: off
00152 0x0097 1 bit CH7 DI set channel
Power-off storage enable on/off
1: on 0: off
00153 0x0098 1 bit CH8 DI set channel
Power-off storage enable on/off
1: on 0: off
00154 0x0099 1 bit CH9 DI set channel
Power-off storage enable on/off
1: on 0: off
00155 0x009A 1 bit CH10 DI set channel
Power-off storage enable on/off
1: on 0: off
00156 0x009B 1 bit CH11 DI set channel
Power-off storage enable on/off
1: on 0: off
00157 0x009C 1 bit DIO 0
1: output DO mode
0: input DI mode
00158 0x009D 1 bit DIO 1
1: output DO mode
0: input DI mode
00159 0x009E 1 bit DIO 2
1: output DO mode
0: input DI mode
00160 0x009F 1 bit DIO 3
1: output DO mode
0: input DI mode
1xxxx Read Only Coils (Function 2)
Reference Address Data Type Description
10001 0x0000 1 bit CH0 DI value
10002 0x0001 1 bit CH1 DI value
10003 0x0002 1 bit CH2 DI value
10004 0x0003 1 bit CH3 DI value
10005 0x0004 1 bit CH4 DI value
10006 0x0005 1 bit CH5 DI value
10007 0x0006 1 bit CH6 DI value
10008 0x0007 1 bit CH7 DI value
10009 0x0008 1 bit CH8 DI value
