ioLogik E2200 Series Modbus/TCP Address Mappings
I-20
Reference Address Data Type Description
00095 0x005E 1 bit CH10 DI clear count value
Read:
0: no action
Write:
1: clear counter value
0: return illegal data value
00096 0x005F 1 bit CH11 DI clear count value
Read:
0: no action
Write:
1: clear counter value
0: return illegal data value
00097 0x0060 1 bit CH0 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00098 0x0061 1 bit CH1 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00099 0x0062 1 bit CH2 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00100 0x0063 1 bit CH3 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00101 0x0064 1 bit CH4 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00102 0x0065 1 bit CH5 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
