ioLogik E2200 Series CGI Commands
G-10
ioLogik E2214
Commands to get system information Commands to get system information
DATE FWR_V
TIME MOD_NAME
IP SN_NUM
LOC MAC_ADDR
DESC
Commands to get DI information Commands to get DI information
DIMode_00
(0:DI, 1:COUNTER)
DIMode_01
(0:DI, 1:COUNTER)
DIStatus_00
(0:OFF, 1:ON)
DIStatus_01
(0:OFF, 1:ON)
DIFilter_00 DIFilter_01
DITrigger_00
(0:LOW TO HIGH, 1:HIGH TO LOW, 2:BOTH)
DITrigger_01
(0:LOW TO HIGH, 1:HIGH TO LOW, 2:BOTH)
DICntStart_00
(0:STOP, 1:START)
DICntStart_01
(0:STOP, 1:START)
DICNT_00 DICNT_01
DIMode_02
(0:DI, 1:COUNTER)
DIMode_03
(0:DI, 1:COUNTER)
DIStatus_02
(0:OFF, 1:ON)
DIStatus_03
(0:OFF, 1:ON)
DIFilter_02 DIFilter_03
DITrigger_02
(0:LOW TO HIGH, 1:HIGH TO LOW, 2:BOTH)
DITrigger_03
(0:LOW TO HIGH, 1:HIGH TO LOW, 2:BOTH)
DICntStart_02
(0:STOP, 1:START)
DICntStart_03
(0:STOP, 1:START)
DICNT_02 DICNT_03
DIMode_04
(0:DI, 1:COUNTER)
DIMode_05
(0:DI, 1:COUNTER)
DIStatus_04
(0:OFF, 1:ON)
DIStatus_05
(0:OFF, 1:ON)
DIFilter_04 DIFilter_05
DITrigger_04
(0:LOW TO HIGH, 1:HIGH TO LOW, 2:BOTH)
DITrigger_05
(0:LOW TO HIGH, 1:HIGH TO LOW, 2:BOTH)
DICntStart_04
(0:STOP, 1:START)
DICntStart_05
(0:STOP, 1:START)
DICNT_04 DICNT_05
Commands to get DO information Commands to get DO information
DOMode_00
(0:DO, 1:PULSE OUTPUT)
DOMode_01
(0:DO, 1:PULSE OUTPUT)
DOStatus_00
(0:OFF, 1:ON)
DOStatus_01
(0:OFF, 1:ON)
DOLowWidth_00 DOLowWidth_01
DOHighWidth_00 DOHighWidth_01
DOPulseStart_00
(0:STOP, 1:START)
DOPulseStart_01
(0:STOP, 1:START)
DOTotalRelayCNT_00 DOTotalRelayCNT_01
DOCurrentRelayCNT_00 DOCurrentRelayCNT_01
