Moxa ioLogik E2210 [33/263] System requirements
![Moxa ioLogik E2210 [33/263] System requirements](/views2/1201325/page33/bg21.png)
ioLogik E2200 Series Using ioAdmin
3-2
System Requirements
The ioLogik E2200 series device can be managed and configured by Ethernet with the ioAdmin Windows utility.
ioAdmin’s graphical user interface provides easy access to all status information and settings. ioAdmin can also
be used to configure Click&Go rules to handle front-end events.
Hardware Requirements
CPU Intel Pentium (Pentium 4 and above)
RAM 512 MB (1024 MB recommended)
Network Interface 10/100Mb Ethernet
Software Requirements
Operating System Microsoft Windows 2000, XP or later
Editor(Not necessary) Microsoft Office 2003 (Access 2003) or later
Features of ioAdmin
Remote management
Use ioAdmin to perform the following task over an Ethernet network:
• Search and configure multiple ioLogiks
• Monitor and control I/O statuses
• Use active message monitoring
• Configure Click&Go local control logic
• Upgrade the firmware
• Restart the ioLogik
• Restore factory default settings
On-line Wiring Guide
For added convenience, a wiring guide is available inside the ioAdmin utility to save time when troubleshooting
or expanding a network.
Configuration File
ioAdmin helps you save all ioLogik configurations as a file. The file is viewable in text format and can be used
as a:
• Record or backup of your configuration
• Template for configuring other ioLogik units
• Quick reference guide for configuring Modbus drivers in a SCADA system
The file includes the following information:
• File name, date, and time
• Model information
• System configuration
• I/O Modbus address
Device Management List
ioAdmin can import and export a list of ioLogik devices that are being managed. This file can make it easier to
manage all devices on the network, and includes the following information:
• Device name
• Module
• IP address
• Unit ID
