ioLogik E2200 Series Modbus/TCP Address Mappings
I-80
Reference Address Data Type Description
40062 0x003D 1 word Virtual CH9 RTD Reset Minimum Value
40063 0x003E 1 word Virtual CH10 RTD Reset Minimum Value
40064 0x003F 1 word Virtual CH11 RTD Reset Minimum Value
40065 0x0040 1 word CH0 RTD Reset Maximum Value
<R> Always 0
<W> 1=Reset, 0=return illegal data value
40066 0x0041 1 word CH1 RTD Reset Maximum Value
40067 0x0042 1 word CH2 RTD Reset Maximum Value
40068 0x0043 1 word CH3 RTD Reset Maximum Value
40069 0x0044 1 word CH4 RTD Reset Maximum Value
40070 0x0045 1 word CH5 RTD Reset Maximum Value
40071 0x0046 1 word Virtual CH6 RTD Reset Maximum Value
40072 0x0047 1 word Virtual CH7 RTD Reset Maximum Value
40073 0x0048 1 word Virtual CH8 RTD Reset Maximum Value
40074 0x0049 1 word Virtual CH9 RTD Reset Maximum Value
40075 0x004A 1 word Virtual CH10 RTD Reset Maximum Value
40076 0x004B 1 word Virtual CH11 RTD Reset Maximum Value
40077 0x004C 1 word CH0 DO Status
<RW> 0=OFF, 1=ON
40078 0x004D 1 word CH1 DO Status
40079 0x004E 1 word CH2 DO Status
40080 0x004F 1 word CH3 DO Status
40081 0x0050 1 word CH0 DO Power On Status
<RW> 0=OFF, 1=ON
40082 0x0051 1 word CH1 DO Status
40083 0x0052 1 word CH2 DO Status
40084 0x0053 1 word CH3 DO Status
40085 0x0054 1 word CH0 DO Safe Status
<RW> 0=OFF, 1=ON
40086 0x0055 1 word CH1 DO Status
40087 0x0056 1 word CH2 DO Status
40088 0x0057 1 word CH3 DO Status
40089 0x0058 1 word CH0 DO Pulse Output Status
<RW> 0=Stop, 1=Start
40090 0x0059 1 word CH1 DO Pulse Output Status
40091 0x005A 1 word CH2 DO Pulse Output Status
40092 0x005B 1 word CH3 DO Pulse Output Status
40093 0x005C 1 word CH0 DO Power On Pulse Output Status
<RW> 0=Stop, 1=Start
40094 0x005D 1 word CH1 DO Pulse Output Status
40095 0x005E 1 word CH2 DO Pulse Output Status
40096 0x005F 1 word CH3 DO Pulse Output Status
40097 0x0060 1 word CH0 DO Safe Pulse Output Status
<RW> 0=Stop, 1=Start
40098 0x0061 1 word CH1 DO Pulse Output Status
40099 0x0062 1 word CH2 DO Pulse Output Status
40100 0x0063 1 word CH3 DO Pulse Output Status
40101 0x0064 1 word CH0 RTD Enable
<RW> 0 =Disable, 1=Enable
40102 0x0065 1 word CH1 RTD Enable
40103 0x0066 1 word CH2 RTD Enable
40104 0x0067 1 word CH3 RTD Enable
