ioLogik E2200 Series Modbus/TCP Address Mappings
I-56
Reference Address Data Type Description
40181 0x01B4 1 word AI Channel 2 Scale Min Value Hi-Word
40182 0x01B5 1 word AI Channel 2 Scale Min Value Low-Word
40183 0x01B6 1 word AI Channel 3 Scale Min Value Hi-Word
40184 0x01B7 1 word AI Channel 3 Scale Min Value Low-Word
40185 0x01B8 1 word AI Channel 4 Scale Min Value Hi-Word
40186 0x01B9 1 word AI Channel 4 Scale Min Value Low-Word
40187 0x01BA 1 word AI Channel 5 Scale Min Value Hi-Word
40188 0x01BB 1 word AI Channel 5 Scale Min Value Low-Word
40189 0x01BC 1 word AI Channel 6 Scale Min Value Hi-Word
40190 0x01BD 1 word AI Channel 6 Scale Min Value Low-Word
40191 0x01BE 1 word AI Channel 7 Scale Min Value Hi-Word
40192 0x01BF 1 word AI Channel 7 Scale Min Value Low-Word
40193 0x01C0 1 word AI Channel 0 Scale Max Value Hi-Word
40194 0x01C1 1 word AI Channel 0 Scale Max Value Low-Word
40195 0x01C2 1 word AI Channel 1 Scale Max Value Hi-Word
40196 0x01C3 1 word AI Channel 1 Scale Max Value Low-Word
40197 0x01C4 1 word AI Channel 2 Scale Max Value Hi-Word
40198 0x01C5 1 word AI Channel 2 Scale Max Value Low-Word
40199 0x01C6 1 word AI Channel 3 Scale Max Value Hi-Word
40200 0x01C7 1 word AI Channel 3 Scale Max Value Low-Word
40201 0x01C8 1 word AI Channel 4 Scale Max Value Hi-Word
40202 0x01C9 1 word AI Channel 4 Scale Max Value Low-Word
40203 0x01CA 1 word AI Channel 5 Scale Max Value Hi-Word
40204 0x01CB 1 word AI Channel 5 Scale Max Value Low-Word
40205 0x01CC 1 word AI Channel 6 Scale Max Value Hi-Word
40206 0x01CD 1 word AI Channel 6 Scale Max Value Low-Word
40207 0x01CE 1 word AI Channel 7 Scale Max Value Hi-Word
40208 0x01CF 1 word AI Channel 7 Scale Max Value Low-Word
40257 0x0100 1 word AI Channel 0 Scale Value Hi-Word (float)
40258 0x0101 1 word AI Channel 0 Scale Value Lo-Word (float)
40259 0x0102 1 word AI Channel 1 Scale Value Hi-Word (float)
40260 0x0103 1 word AI Channel 1 Scale Value Lo-Word (float)
40261 0x0104 1 word AI Channel 2 Scale Value Hi-Word (float)
40262 0x0105 1 word AI Channel 2 Scale Value Lo-Word (float)
40263 0x0106 1 word AI Channel 3 Scale Value Hi-Word (float)
40264 0x0107 1 word AI Channel 3 Scale Value Lo-Word (float)
40265 0x0108 1 word AI Channel 4 Scale Value Hi-Word (float)
40266 0x0109 1 word AI Channel 4 Scale Value Lo-Word (float)
40267 0x010A 1 word AI Channel 5 Scale Value Hi-Word (float)
40268 0x010B 1 word AI Channel 5 Scale Value Lo-Word (float)
40269 0x010C 1 word AI Channel 6 Scale Value Hi-Word (float)
40270 0x010D 1 word AI Channel 6 Scale Value Lo-Word (float)
40271 0x010E 1 word AI Channel 7 Scale Value Hi-Word (float)
40272 0x010F 1 word AI Channel 7 Scale Value Lo-Word (float)
40337 0x0150 1 word Internal Register 00 Working Value
40338 0x0151 1 word Internal Register 01 Working Value
40339 0x0152 1 word Internal Register 02 Working Value
40340 0x0153 1 word Internal Register 03 Working Value
40341 0x0154 1 word Internal Register 04 Working Value
40342 0x0155 1 word Internal Register 05 Working Value
40343 0x0156 1 word Internal Register 06 Working Value
40344 0x0157 1 word Internal Register 07 Working Value
