ioLogik E2200 Series Modbus/TCP Address Mappings
I-37
Reference Address Data Type Description
42943 0x0B7E word Internal Register 22 Working Value
42944 0x0B7F word Internal Register 23 Working Value
43329 0x0D00 2 word CH0 DI - Counter mode value
43330 0x0D01 2 word CH1 DI - Counter mode value
43331 0x0D02 2 word CH2 DI - Counter mode value
43332 0x0D03 2 word CH3 DI - Counter mode value
43333 0x0D04 2 word CH4 DI - Counter mode value
43334 0x0D05 2 word CH5 DI - Counter mode value
43335 0x0D06 2 word CH6 DI - Counter mode value
43336 0x0D07 2 word CH7 DI - Counter mode value
43337 0x0D08 2 word CH8 DI - Counter mode value
43338 0x0D09 2 word CH9 DI - Counter mode value
43339 0x0D0A 2 word CH10 DI - Counter mode value
43340 0x0D0B 2 word CH11 DI - Counter mode value
ioLogik E2214 Modbus Mapping
0xxxx Read/Write Coils (Support Functions 1, 5, 15)
Reference Address Data Type Description
00001 0x0000 1 bit CH0 DO Value 0: Off 1: On
00002 0x0001 1 bit CH1 DO Value 0: Off 1: On
00003 0x0002 1 bit CH2 DO Value 0: Off 1: On
00004 0x0003 1 bit CH3 DO Value 0: Off 1: On
00005 0x0004 1 bit CH4 DO Value 0: Off 1: On
00006 0x0005 1 bit CH5 DO Value 0: Off 1: On
00007 0x0006 1 bit CH0 DO Power On Value 0: Off 1: On
00008 0x0007 1 bit CH1 DO Power On Value 0: Off 1: On
00009 0x0008 1 bit CH2 DO Power On Value 0: Off 1: On
00010 0x0009 1 bit CH3 DO Power On Value 0: Off 1: On
00011 0x000A 1 bit CH4 DO Power On Value 0: Off 1: On
00012 0x000B 1 bit CH5 DO Power On Value 0: Off 1: On
00013 0x000C 1 bit CH0 DO Pulse Operate Status 0: Off 1: On
00014 0x000D 1 bit CH1 DO Pulse Operate Status 0: Off 1: On
00015 0x000E 1 bit CH2 DO Pulse Operate Status 0: Off 1: On
00016 0x000F 1 bit CH3 DO Pulse Operate Status 0: Off 1: On
00017 0x0010 1 bit CH4 DO Pulse Operate Status 0: Off 1: On
00018 0x0011 1 bit CH5 DO Pulse Operate Status 0: Off 1: On
00019 0x0012 1 bit CH0 DO PowerOn Pulse Operate Status 0: Off 1: On
00020 0x0013 1 bit CH1 DO PowerOn Pulse Operate Status 0: Off 1: On
00021 0x0014 1 bit CH2 DO PowerOn Pulse Operate Status 0: Off 1: On
00022 0x0015 1 bit CH3 DO PowerOn Pulse Operate Status 0: Off 1: On
00023 0x0016 1 bit CH4 DO PowerOn Pulse Operate Status 0: Off 1: On
00024 0x0017 1 bit CH5 DO PowerOn Pulse Operate Status 0: Off 1: On
00025 0x0018 1 bit CH0 DO Safe Pulse Operate Status 0: Off 1: On
00026 0x0019 1 bit CH1 DO Safe Pulse Operate Status 0: Off 1: On
00027 0x001A 1 bit CH2 DO Safe Pulse Operate Status 0: Off 1: On
00028 0x001B 1 bit CH3 DO Safe Pulse Operate Status 0: Off 1: On
00029 0x001C 1 bit CH4 DO Safe Pulse Operate Status 0: Off 1: On
00030 0x001D 1 bit CH5 DO Safe Pulse Operate Status 0: Off 1: On
