ioLogik E2200 Series Modbus/TCP Address Mappings
I-34
Reference Address Data Type Description
40198 0x00C5 1 word CH5 DI counter trigger
0=low to high, 1=high to low
40199 0x00C6 1 word CH6 DI counter trigger
0=low to high, 1=high to low
40200 0x00C7 1 word CH7 DI counter trigger
0=low to high, 1=high to low
40201 0x00C8 1 word CH8 DI counter trigger
0=low to high, 1=high to low
40202 0x00C9 1 word CH9 DI counter trigger
0=low to high, 1=high to low
40203 0x00CA 1 word CH10 DI counter trigger
0=low to high, 1=high to low
40204 0x00CB 1 word CH11 DI counter trigger
0=low to high, 1=high to low
40205 0x00CC 1 word CH0 DI power-on counter operate status
0: stop 1: start
40206 0x00CD 1 word CH1 DI power-on counter operate status
0: stop 1: start
40207 0x00CE 1 word CH2 DI power-on counter operate status
0: stop 1: start
40208 0x00CF 1 word CH3 DI power-on counter operate status
0: stop 1: start
40209 0x00D0 1 word CH4 DI power-on counter operate status
0: stop 1: start
40210 0x00D1 1 word CH5 DI power-on counter operate status
0: stop 1: start
40211 0x00D2 1 word CH6 DI power-on counter operate status
0: stop 1: start
40212 0x00D3 1 word CH7 DI power-on counter operate status
0: stop 1: start
40213 0x00D4 1 word CH8 DI power-on counter operate status
0: stop 1: start
40214 0x00D5 1 word CH9 DI power-on counter operate status
0: stop 1: start
40215 0x00D6 1 word CH10 DI power-on counter operate status
0: stop 1: start
40216 0x00D7 1 word CH11 DI power-on counter operate status
0: stop 1: start
40217 0x00D8 1 word CH0 DI safe mode counter operate status
0: stop 1: start
40218 0x00D9 1 word CH1 DI safe mode counter operate status
0: stop 1: start
40219 0x00DA 1 word CH2 DI safe mode counter operate status
0: stop 1: start
40220 0x00DB 1 word CH3 DI safe mode counter operate status
0: stop 1: start
40221 0x00DC 1 word CH4 DI safe mode counter operate status
0: stop 1: start
40222 0x00DD 1 word CH5 DI safe mode counter operate status
0: stop 1: start
40223 0x00DE 1 word CH6 DI safe mode counter operate status
0: stop 1: start
