ioLogik E2200 Series Using ioAdmin
3-3
Server Management List
ioAdmin can import and export a list of ioLogik units
that are being managed. This file can make it easier
to manage all devices on the network, and includes
the following information:
•
Server name
•
Module
•
IP address
•
Unit ID
ioAdmin Overview
Main Screen Overview
The main screen of the ioAdmin utility defaults to the I/O Configuration tab, which displays a figure of your
ioLogik device with the status of each of its I/O channels. The other tabs on the main screen take you to server
and network settings, and further functions are available when you log on to the ioLogik. Note that
configuration options are not available unless you log on as an administrator.
ioAdmin Main Screen
1. Title
2. Menu bar
3. Quick link
4. Navigation panel
5. Main window
6. Sync. rate status
7. Status bar
1
2
4
6
5
7
3
