ioLogik E2200 Series Modbus/TCP Address Mappings
I-86
Reference Address Data Type Description
40018 0x0011 1 word CH0 DO Pulse Output High Signal Width – Lo Word
<RW> 0~4294967295
40019 0x0012 1 word CH1 DO Pulse Output High Signal Width – Hi Word
40020 0x0013 1 word CH1 DO Pulse Output High Signal Width – Lo Word
40021 0x0014 1 word CH2 DO Pulse Output High Signal Width – Hi Word
40022 0x0015 1 word CH2 DO Pulse Output High Signal Width – Lo Word
40023 0x0016 1 word CH3 DO Pulse Output High Signal Width – Hi Word
40024 0x0017 1 word CH3 DO Pulse Output High Signal Width – Lo Word
40025 0x0018 1 word CH0 DO Operation Mode
<RW> 0=DO Mode, 1=Pulse Output Mode
40026 0x0019 1 word CH1 DO Operation Mode
40027 0x001A 1 word CH2 DO Operation Mode
40028 0x001B 1 word CH3 DO Operation Mode
40029 0x001C 1 word CH0 TC Engineering Unit
0=Celsius, 1=Fahrenheit, 2=millivolt
40030 0x001D 1 word CH1 TC Engineering Unit
40031 0x001E 1 word CH2 TC Engineering Unit
40032 0x001F 1 word CH3 TC Engineering Unit
40033 0x0020 1 word CH4 TC Engineering Unit
40034 0x0021 1 word CH5 TC Engineering Unit
40035 0x0022 1 word CH6 TC Engineering Unit
40036 0x0023 1 word CH7 TC Engineering Unit
40037 0x0024 1 word Virtual CH8 TC Engineering Unit
0=Celsius, 1=Fahrenheit, 2= millivolt
40038 0x0025 1 word Virtual CH9 TC Engineering Unit
40039 0x0026 1 word Virtual CH10 TC Engineering Unit
40040 0x0027 1 word Virtual CH11 TC Engineering Unit
40041 0x0028 1 word Virtual CH12 TC Engineering Unit
40042 0x0029 1 word Virtual CH13 TC Engineering Unit
40043 0x002A 1 word Virtual CH14 TC Engineering Unit
40044 0x002B 1 word Virtual CH15 TC Engineering Unit
40045 0x002C 1 word CH0 TC Sensor Type
0=J Type
1=K Type
2=T Type
3=E Type
4=R Type
5=S Type
6=B Type
7=N Type
8=Voltage:78.126mV
9=Voltage:39.062mV
10=Voltage:19.532mV
40046 0x002D 1 word CH1 TC Sensor Type
40047 0x002E 1 word CH2 TC Sensor Type
40048 0x002F 1 word CH3 TC Sensor Type
40049 0x0030 1 word CH4 TC Sensor Type
40050 0x0031 1 word CH5 TC Sensor Type
40051 0x0032 1 word CH6 TC Sensor Type
40052 0x0033 1 word CH7 TC Sensor Type
