ioLogik E2200 Series Modbus/TCP Address Mappings
I-44
Reference Address Data Type Description
40077 0x004C 1 word CH4 DO Safe Mode Pulse Operate Status 0: Stop 1: Start
40078 0x004D 1 word CH5 DO Safe Mode Pulse Operate Status 0: Stop 1: Start
40079 0x004E 1 word CH0 DI Counter Operate Status 0: Stop 1: Start
40080 0x004F 1 word CH1 DI Counter Operate Status 0: Stop 1: Start
40081 0x0050 1 word CH2 DI Counter Operate Status 0: Stop 1: Start
40082 0x0051 1 word CH3 DI Counter Operate Status 0: Stop 1: Start
40083 0x0052 1 word CH4 DI Counter Operate Status 0: Stop 1: Start
40084 0x0053 1 word CH5 DI Counter Operate Status 0: Stop 1: Start
40085 0x0054 1 word CH0 DI Clear Count Value
Read: always return: 0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40086 0x0055 1 word CH1 DI Clear Count Value
Read: always return: 0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40087 0x0056 1 word CH2 DI Clear Count Value
Read always return: 0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40088 0x0057 1 word CH3 DI Clear Count Value
Read: always return: 0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40089 0x0058 1 word CH4 DI Clear Count Value
Read: always return: 0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40090 0x0059 1 word CH5 DI Clear Count Value
Read: always return: 0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
40091 0x005A 1 word CH0 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40092 0x005B 1 word CH1 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40093 0x005C 1 word CH2 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40094 0x005D 1 word CH3 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
