ioLogik E2200 Series Click&Go
4-3
Click&Go Logic Basics
To use Click&Go Logic, open ioAdmin and log on as an ioLogik administrator on the Server Settings panel. Once
you are logged on, go to the Click&Go Logic panel. It should appear as below:
Click&Go Logic Panel
1. Global Variable: In this field, you can assign a Global Variable for the set of rules.
2. Logic Name: In this field, you can assign a name for the set of rules.
3. Rules List: In this area, each rule’s conditions, actions, and status are displayed.
4. Ruleset Management Bar: In this area, you manage the ruleset.
