ioLogik E2200 Series Modbus/TCP Address Mappings
I-46
Reference Address Data Type Description
40122 0x0079 1 Word CH0 DO Current Relay Count Value Lo-Byte
40123 0x007A 1 Word CH1 DO Current Relay Count Value Hi-Byte
40124 0x007B 1 Word CH1 DO Current Relay Count Value Lo-Byte
40125 0x007C 1 Word CH2 DO Current Relay Count Value Hi-Byte
40126 0x007D 1 Word CH2 DO Current Relay Count Value Lo-Byte
40127 0x007E 1 Word CH3 DO Current Relay Count Value Hi-Byte
40128 0x007F 1 Word CH3 DO Current Relay Count Value Lo-Byte
40129 0x0080 1 Word CH4 DO Current Relay Count Value Hi-Byte
40130 0x0081 1 Word CH4 DO Current Relay Count Value Lo-Byte
40131 0x0082 1 Word CH5 DO Current Relay Count Value Hi-Byte
40132 0x0083 1 Word CH5 DO Current Relay Count Value Lo-Byte
40133 0x0084 1 Word Power On Sequence
CH0 DO Delay time (MAX 300 Seconds)
40134 0x0085 1 Word Power On Sequence
CH1 DO Delay time(MAX 300 Seconds)
40135 0x0086 1 Word Power On Sequence
CH2 DO Delay time(MAX 300 Seconds)
40136 0x0087 1 Word Power On Sequence
CH3 DO Delay time(MAX 300 Seconds)
40137 0x0088 1 Word Power On Sequence
CH4 DO Delay time(MAX 300 Seconds)
40138 0x0089 1 Word Power On Sequence
CH5 DO Delay time(MAX 300 Seconds)
40377 0x0178 1 Word Internal Register 00 Initial Value
40378 0x0179 1 Word Internal Register 01 Initial Value
40379 0x017A 1 Word Internal Register 02 Initial Value
40380 0x017B 1 Word Internal Register 03 Initial Value
40381 0x017C 1 Word Internal Register 04 Initial Value
40382 0x017D 1 Word Internal Register 05 Initial Value
40383 0x017E 1 Word Internal Register 06 Initial Value
40384 0x017F 1 Word Internal Register 07 Initial Value
40385 0x0180 1 Word Internal Register 08 Initial Value
40386 0x0181 1 Word Internal Register 09 Initial Value
40387 0x0182 1 Word Internal Register 10 Initial Value
40388 0x0183 1 Word Internal Register 11 Initial Value
40389 0x0184 1 Word Internal Register 12 Initial Value
40390 0x0185 1 Word Internal Register 13 Initial Value
40391 0x0186 1 Word Internal Register 14 Initial Value
40392 0x0187 1 Word Internal Register 15 Initial Value
40393 0x0188 1 Word Internal Register 16 Initial Value
40394 0x0189 1 Word Internal Register 17 Initial Value
40395 0x018A 1 Word Internal Register 18 Initial Value
40396 0x018B 1 Word Internal Register 19 Initial Value
40397 0x018C 1 Word Internal Register 20 Initial Value
40398 0x018D 1 Word Internal Register 21 Initial Value
40399 0x018E 1 Word Internal Register 22 Initial Value
40400 0x018F 1 Word Internal Register 23 Initial Value
42921 0x0B68 word Internal Register 00 Working Value
42922 0x0B69 word Internal Register 01 Working Value
42923 0x0B6A word Internal Register 02 Working Value
42924 0x0B6B word Internal Register 03 Working Value
42925 0x0B6C word Internal Register 04 Working Value
