ioLogik E2200 Series Modbus/TCP Address Mappings
I-58
Reference Address Data Type Description
00029 0x001C 1 bit CH4 DO Safe Value 0: Off 1: On
00030 0x001D 1 bit CH5 DO Safe Value 0: Off 1: On
00031 0x001E 1 bit CH6 DO Safe Value 0: Off 1: On
00032 0x001F 1 bit CH7 DO Safe Value 0: Off 1: On
00033 0x0020 1 bit CH8 DO Safe Value 0: Off 1: On
00034 0x0021 1 bit CH9 DO Safe Value 0: Off 1: On
00035 0x0022 1 bit CH10 DO Safe Value 0: Off 1: On
00036 0x0023 1 bit CH11 DO Safe Value 0: Off 1: On
00037 0x0024 1 bit CH0 DO Pulse Operate Status 0: Off 1: On
00038 0x0025 1 bit CH1 DO Pulse Operate Status 0: Off 1: On
00039 0x0026 1 bit CH2 DO Pulse Operate Status 0: Off 1: On
00040 0x0027 1 bit CH3 DO Pulse Operate Status 0: Off 1: On
00041 0x0028 1 bit CH4 DO Pulse Operate Status 0: Off 1: On
00042 0x0029 1 bit CH5 DO Pulse Operate Status 0: Off 1: On
00043 0x002A 1 bit CH6 DO Pulse Operate Status 0: Off 1: On
00044 0x002B 1 bit CH7 DO Pulse Operate Status 0: Off 1: On
00045 0x002C 1 bit CH8 DO Pulse Operate Status 0: Off 1: On
00046 0x002D 1 bit CH9 DO Pulse Operate Status 0: Off 1: On
00047 0x002E 1 bit CH10 DO Pulse Operate Status 0: Off 1: On
00048 0x002F 1 bit CH11 DO Pulse Operate Status 0: Off 1: On
00049 0x0030 1 bit CH0 DO PowerOn Pulse Operate Status 0: Off 1: On
00050 0x0031 1 bit CH1 DO PowerOn Pulse Operate Status 0: Off 1: On
00051 0x0032 1 bit CH2 DO PowerOn Pulse Operate Status 0: Off 1: On
00052 0x0033 1 bit CH3 DO PowerOn Pulse Operate Status 0: Off 1: On
00053 0x0034 1 bit CH4 DO PowerOn Pulse Operate Status 0: Off 1: On
00054 0x0035 1 bit CH5 DO PowerOn Pulse Operate Status 0: Off 1: On
00055 0x0036 1 bit CH6 DO PowerOn Pulse Operate Status 0: Off 1: On
00056 0x0037 1 bit CH7 DO PowerOn Pulse Operate Status 0: Off 1: On
00057 0x0038 1 bit CH8 DO PowerOn Pulse Operate Status 0: Off 1: On
00058 0x0039 1 bit CH9 DO PowerOn Pulse Operate Status 0: Off 1: On
00059 0x003A 1 bit CH10 DO PowerOn Pulse Operate Status 0: Off 1: On
00060 0x003B 1 bit CH11 DO PowerOn Pulse Operate Status 0: Off 1: On
00061 0x003C 1 bit CH0 DO Safe Pulse Operate Status 0: Off 1: On
00062 0x003D 1 bit CH1 DO Safe Pulse Operate Status 0: Off 1: On
00063 0x003E 1 bit CH2 DO Safe Pulse Operate Status 0: Off 1: On
00064 0x003F 1 bit CH3 DO Safe Pulse Operate Status 0: Off 1: On
00065 0x0040 1 bit CH4 DO Safe Pulse Operate Status 0: Off 1: On
00066 0x0041 1 bit CH5 DO Safe Pulse Operate Status 0: Off 1: On
00067 0x0042 1 bit CH6 DO Safe Pulse Operate Status 0: Off 1: On
00068 0x0043 1 bit CH7 DO Safe Pulse Operate Status 0: Off 1: On
00069 0x0044 1 bit CH8 DO Safe Pulse Operate Status 0: Off 1: On
00070 0x0045 1 bit CH9 DO Safe Pulse Operate Status 0: Off 1: On
00071 0x0046 1 bit CH10 DO Safe Pulse Operate Status 0: Off 1: On
00072 0x0047 1 bit CH11 DO Safe Pulse Operate Status 0: Off 1: On
00073 0x0048 1 bit CH0 DI Counter Status 0: Off 1: On
00074 0x0049 1 bit CH1 DI Counter Status 0: Off 1: On
00075 0x004A 1 bit CH2 DI Counter Status 0: Off 1: On
00076 0x004B 1 bit CH3 DI Counter Status 0: Off 1: On
00077 0x004C 1 bit CH4 DI Counter Status 0: Off 1: On
00078 0x004D 1 bit CH5 DI Counter Status 0: Off 1: On
00079 0x004E 1 bit CH6 DI Counter Status 0: Off 1: On
00080 0x004F 1 bit CH7 DI Counter Status 0: Off 1: On
