ioLogik E2200 Series Modbus/TCP Address Mappings
I-66
Reference Address Data Type Description
40024 0x0017 1 word CH11 DO Pulse Output Count Value Lo- Word
40025 0x0018 1 word CH0 DO Pulse Low Signal Width Hi- Word
40026 0x0019 1 word CH0 DO Pulse Low Signal Width Lo- Word
40027 0x001A 1 word CH1 DO Pulse Low Signal Width Hi- Word
40028 0x001B 1 word CH1 DO Pulse Low Signal Width Lo- Word
40029 0x001C 1 word CH2 DO Pulse Low Signal Width Hi- Word
40030 0x001D 1 word CH2 DO Pulse Low Signal Width Lo- Word
40031 0x001E 1 word CH3 DO Pulse Low Signal Width Hi- Word
40032 0x001F 1 word CH3 DO Pulse Low Signal Width Lo- Word
40033 0x0020 1 word CH4 DO Pulse Low Signal Width Hi- Word
40034 0x0021 1 word CH4 DO Pulse Low Signal Width Lo- Word
40035 0x0022 1 word CH5 DO Pulse Low Signal Width Hi- Word
40036 0x0023 1 word CH5 DO Pulse Low Signal Width Lo- Word
40037 0x0024 1 word CH6 DO Pulse Low Signal Width Hi- Word
40038 0x0025 1 word CH6 DO Pulse Low Signal Width Lo- Word
40039 0x0026 1 word CH7 DO Pulse Low Signal Width Hi- Word
40040 0x0027 1 word CH7 DO Pulse Low Signal Width Lo- Word
40041 0x0028 1 word CH8 DO Pulse Low Signal Width Hi- Word
40042 0x0029 1 word CH8 DO Pulse Low Signal Width Lo- Word
40043 0x002A 1 word CH9 DO Pulse Low Signal Width Hi- Word
40044 0x002B 1 word CH9 DO Pulse Low Signal Width Lo- Word
40045 0x002C 1 word CH10 DO Pulse Low Signal Width Hi- Word
40046 0x002D 1 word CH10 DO Pulse Low Signal Width Lo- Word
40047 0x002E 1 word CH11 DO Pulse Low Signal Width Hi- Word
40048 0x002F 1 word CH11 DO Pulse Low Signal Width Lo- Word
40049 0x0030 1 word CH0 DO Pulse High Signal Width Hi- Word
40050 0x0031 1 word CH0 DO Pulse High Signal Width Lo- Word
40051 0x0032 1 word CH1 DO Pulse High Signal Width Hi- Word
40052 0x0033 1 word CH1 DO Pulse High Signal Width Lo- Word
40053 0x0034 1 word CH2 DO Pulse High Signal Width Hi- Word
40054 0x0035 1 word CH2 DO Pulse High Signal Width Lo- Word
40055 0x0036 1 word CH3 DO Pulse High Signal Width Hi- Word
40056 0x0037 1 word CH3 DO Pulse High Signal Width Lo- Word
40057 0x0038 1 word CH4 DO Pulse High Signal Width Hi- Word
40058 0x0039 1 word CH4 DO Pulse High Signal Width Lo- Word
40059 0x003A 1 word CH5 DO Pulse High Signal Width Hi- Word
40060 0x003B 1 word CH5 DO Pulse High Signal Width Lo- Word
40061 0x003C 1 word CH6 DO Pulse High Signal Width Hi- Word
40062 0x003D 1 word CH6 DO Pulse High Signal Width Lo- Word
40063 0x003E 1 word CH7 DO Pulse High Signal Width Hi- Word
40064 0x003F 1 word CH7 DO Pulse High Signal Width Lo- Word
40065 0x0040 1 word CH8 DO Pulse High Signal Width Hi- Word
40066 0x0041 1 word CH8 DO Pulse High Signal Width Lo- Word
40067 0x0042 1 word CH9 DO Pulse High Signal Width Hi- Word
40068 0x0043 1 word CH9 DO Pulse High Signal Width Lo- Word
40069 0x0044 1 word CH10 DO Pulse High Signal Width Hi- Word
40070 0x0045 1 word CH10 DO Pulse High Signal Width Lo- Word
40071 0x0046 1 word CH11 DO Pulse High Signal Width Hi- Word
40072 0x0047 1 word CH11 DO Pulse High Signal Width Lo- Word
40073 0x0048 1 word CH0 DO Mode 0: DO
1: Pulse
