ioLogik E2200 Series Modbus/TCP Address Mappings
I-45
Reference Address Data Type Description
40095 0x005E 1 word CH4 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40096 0x005F 1 word CH5 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40097 0x0060 1 word CH0 DI Counter Trigger, 0=Low to High, 1=High to Low
40098 0x0061 1 word CH1 DI Counter Trigger, 0=Low to High, 1=High to Low
40099 0x0062 1 word CH2 DI Counter Trigger, 0=Low to High, 1=High to Low
40100 0x0063 1 word CH3 DI Counter Trigger, 0=Low to High, 1=High to Low
40101 0x0064 1 word CH4 DI Counter Trigger, 0=Low to High, 1=High to Low
40102 0x0065 1 word CH5 DI Counter Trigger, 0=Low to High, 1=High to Low
40103 0x0066 1 word CH0 DI PowerOn Counter Operate Status 0: Stop 1: Start
40104 0x0067 1 word CH1 DI PowerOn Counter Operate Status 0: Stop 1: Start
40105 0x0068 1 word CH2 DI PowerOn Counter Operate Status 0: Stop 1: Start
40106 0x0069 1 word CH3 DI PowerOn Counter Operate Status 0: Stop 1: Start
40107 0x006A 1 word CH4 DI PowerOn Counter Operate Status 0: Stop 1: Start
40108 0x006B 1 word CH5 DI PowerOn Counter Operate Status 0: Stop 1: Start
40109 0x006C 1 word CH0 DI Safe Mode Counter Operate Status 0: Stop 1: Start
40110 0x006D 1 word CH1 DI Safe Mode Counter Operate Status 0: Stop 1: Start
40111 0x006E 1 word CH2 DI Safe Mode Counter Operate Status 0: Stop 1: Start
40112 0x006F 1 word CH3 DI Safe Mode Counter Operate Status 0: Stop 1: Start
40113 0x0070 1 word CH4 DI Safe Mode Counter Operate Status 0: Stop 1: Start
40114 0x0071 1 word CH5 DI Safe Mode Counter Operate Status 0: Stop 1: Start
40115 0x0072 1 Word CH0 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
40116 0x0073 1 Word CH1 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
40117 0x0074 1 Word CH2 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
40118 0x0075 1 Word CH3 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
40119 0x0076 1 Word CH4 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
40120 0x0077 1 Word CH5 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
40121 0x0078 1 Word CH0 DO Current Relay Count Value Hi-Byte
