ioLogik E2200 Series Modbus/TCP Address Mappings
I-13
Reference Address Data Type Description
40313 0x0138 1 word CH8 DI Counter Operate Status 0: Stop 1: Start
40314 0x0139 1 word CH9 DI Counter Operate Status 0: Stop 1: Start
40315 0x013A 1 word CH10 DI Counter Operate Status 0: Stop 1: Start
40316 0x013B 1 word CH11 DI Counter Operate Status 0: Stop 1: Start
40317 0x013C 1 word CH0 DI Clear Count Value Read: always return: 0 Write: 1 :
Clear counter value0 : Return illegal data value(0x03)
40318 0x013D 1 word CH1 DI Clear Count Value Read: always return: 0 Write: 1 :
Clear counter value 0 : Return illegal data value(0x03)
40319 0x013E 1 word CH2 DI Clear Count Value Read: always return: 0 Write: 1 :
Clear counter value 0 : Return illegal data value(0x03)
40320 0x013F 1 word CH3 DI Clear Count Value Read: always return: 0 Write: 1 :
Clear counter value 0 : Return illegal data value(0x03)
40321 0x0140 1 word CH4 DI Clear Count Value Read: always return: 0 Write: 1 :
Clear counter value 0 : Return illegal data value(0x03)
40322 0x0141 1 word CH5 DI Clear Count Value Read: always return: 0 Write: 1 :
Clear counter value 0 : Return illegal data value(0x03)
40323 0x0142 1 word CH6 DI Clear Count Value Read: always return: 0 Write: 1 :
Clear counter value 0 : Return illegal data value(0x03)
40324 0x0143 1 word CH7 DI Clear Count Value Read: always return: 0 Write: 1 :
Clear counter value 0 : Return illegal data value(0x03)
40325 0x0144 1 word CH8 DI Clear Count Value Read: always return: 0Write: 1 :
Clear counter value 0 : Return illegal data value(0x03)
40326 0x0145 1 word CH9 DI Clear Count Value Read: always return: 0Write: 1 :
Clear counter value 0 : Return illegal data value(0x03)
40327 0x0146 1 word CH10 DI Clear Count Value Read: always return: 0Write: 1 :
Clear counter value 0 : Return illegal data value(0x03)
40328 0x0147 1 word CH11 DI Clear Count Value Read: always return: 0
Write: 1 : Clear counter value0 : Return illegal data
value(0x03)
40329 0x0148 1 word CH0 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40330 0x0149 1 word CH1 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40331 0x014A 1 word CH2 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40332 0x014B 1 word CH3 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40333 0x014C 1 word CH4 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
40334 0x014D 1 word CH5 DI OverFlow Status Read: 0 : Normal
1 : Overflow
Write: 0 : Clear overflow status
1 : Return illegal data value (0x03)
