ioLogik E2200 Series Modbus/TCP Address Mappings
I-21
Reference Address Data Type Description
00103 0x0066 1 bit CH6 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00104 0x0067 1 bit CH7 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00105 0x0068 1 bit CH8 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00106 0x0069 1 bit CH9 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00107 0x006A 1 bit CH10 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00108 0x006B 1 bit CH11 DI overflow status
Read:
0: normal 1: overflow
Write:
0: clear overflow status
1: return illegal data value
00109 0x006C 1 bit CH0 DI count trigger
00110 0x006D 1 bit CH1 DI count trigger
00111 0x006E 1 bit CH2 DI count trigger
00112 0x006F 1 bit CH3 DI count trigger
00113 0x0070 1 bit CH4 DI count trigger
00114 0x0071 1 bit CH5 DI count trigger
00115 0x0072 1 bit CH6 DI count trigger
00116 0x0073 1 bit CH7 DI count trigger
00117 0x0074 1 bit CH8 DI count trigger
00118 0x0075 1 bit CH9 DI count trigger
00119 0x0076 1 bit CH10 DI count trigger
00120 0x0077 1 bit CH11 DI count trigger
00121 0x0078 1 bit CH0 DI power-on status
0: off 1: on
00122 0x0079 1 bit CH1 DI power-on status
0: off 1: on
