ioLogik E2200 Series Modbus/TCP Address Mappings
I-39
Reference Address Data Type Description
00054 0x0035 1 bit CH5 DI Count Trigger
00055 0x0036 1 bit CH0 DI PowerOn Status 0: Off 1: On
00056 0x0037 1 bit CH1 DI PowerOn Status 0: Off 1: On
00057 0x0038 1 bit CH2 DI PowerOn Status 0: Off 1: On
00058 0x0039 1 bit CH3 DI PowerOn Status 0: Off 1: On
00059 0x003A 1 bit CH4 DI PowerOn Status 0: Off 1: On
00060 0x003B 1 bit CH5 DI PowerOn Status 0: Off 1: On
00061 0x003C 1 bit CH0 DI Safe Pulse Operate Status 0: Off 1: On
00062 0x003D 1 bit CH1 DI Safe Pulse Operate Status 0: Off 1: On
00063 0x003E 1 bit CH2 DI Safe Pulse Operate Status 0: Off 1: On
00064 0x003F 1 bit CH3 DI Safe Pulse Operate Status 0: Off 1: On
00065 0x0040 1 bit CH4 DI Safe Pulse Operate Status 0: Off 1: On
00066 0x0041 1 bit CH5 DI Safe Pulse Operate Status 0: Off 1: On
00067 0x0042 1 bit CH0 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00068 0x0043 1 bit CH1 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00069 0x0044 1 bit CH2 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00070 0x0045 1 bit CH3 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00071 0x0046 1 bit CH4 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00072 0x0047 1 bit CH5 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
1xxxx Read Only Coils (Function 2)
Reference Address Data Type Description
10001 0x0000 1 bit CH0 DI Value
10002 0x0001 1 bit CH1 DI Value
10003 0x0002 1 bit CH2 DI Value
10004 0x0003 1 bit CH3 DI Value
10005 0x0004 1 bit CH4 DI Value
10006 0x0005 1 bit CH5 DI Value
