ioLogik E2200 Series Modbus/TCP Address Mappings
I-53
Reference Address Data Type Description
40024 0x0017 1 word CH3 AI power-on range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40025 0x0018 1 word CH4 AI power-on range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40026 0x0019 1 word CH5 AI power-on range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40027 0x001A 1 word CH6 AI power-on range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40028 0x001B 1 word CH7 AI power-on range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40029 0x001C 1 word CH0 AI safe range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
