ioLogik E2200 Series Using ioAdmin

3-32

Click&Go Logic Tab

The Click&Go Logic tab is available after logging in as an administrator. This is where the ioLogik’s device

system is configured. With a set of rules (known as a ruleset) defined through Click&Go, the ioLogik can report

I/O status to a host as soon as user-defined I/O conditions have been met. Refer to the Click&Go V2 User’s

Manual, which can be downloaded from Moxa’s website, for more detailed information on defining rules.

Click&Go Logic changes do not take effect until the ioLogik E2200 series has restarted. Click Upload to

upload the logic values and restart the ioLogik E2200. After logging back in as an administrator and returning

to the Click&Go Logic tab, click Retrieve to view the current ruleset. Click Run to activate the ruleset and Stop

to deactivate it.

To learn more about “Click&Go” please refer to the following website:

http://www.moxa.com/remote_io/ClicknGo.htm

ATTENTION

I/O channels used by Click&Go Logic

cannot be controlled externally using ioAdmin’s Test function,

other

Modbus/TCP master software, SCADA software, or SMS commands.
