ioLogik E2200 Series Modbus/TCP Address Mappings
I-68
Reference Address Data Type Description
40101 0x0064 1 word CH4 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40102 0x0065 1 word CH5 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40103 0x0066 1 word CH6 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40104 0x0067 1 word CH7 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40105 0x0068 1 word CH8 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40106 0x0069 1 word CH9 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40107 0x006A 1 word CH10 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40108 0x006B 1 word CH11 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40109 0x006C 1 word CH0 AI set/get Enable 1:Enable , 0: Disable
40110 0x006D 1 word CH1 AI set/get Enable 1:Enable , 0: Disable
40111 0x006E 1 word CH2 AI set/get Enable 1:Enable , 0: Disable
40112 0x006F 1 word CH3 AI set/get Enable 1:Enable , 0: Disable
40129 0x0080 1 word CH0 DO set/get wordvalue ; 0: Off 1:On
40130 0x0081 1 word CH1 DO set/get wordvalue ; 0: Off 1:On
40131 0x0082 1 word CH2 DO set/get wordvalue ; 0: Off 1:On
40132 0x0083 1 word CH3 DO set/get wordvalue ; 0: Off 1:On
40133 0x0084 1 word CH4 DO set/get wordvalue ; 0: Off 1:On
40134 0x0085 1 word CH5 DO set/get wordvalue ; 0: Off 1:On
40135 0x0086 1 word CH6 DO set/get wordvalue ; 0: Off 1:On
40136 0x0087 1 word CH7 DO set/get wordvalue ; 0: Off 1:On
40137 0x0088 1 word CH8 DO set/get wordvalue ; 0: Off 1:On
40138 0x0089 1 word CH9 DO set/get wordvalue ; 0: Off 1:On
40139 0x008A 1 word CH10 DO set/get wordvalue ; 0: Off 1:On
40140 0x008B 1 word CH11 DO set/get wordvalue ; 0: Off 1:On
40141 0x008C 1 word CH0 DO set/get poweron wordvalue
40142 0x008D 1 word CH1 DO set/get poweron wordvalue
40143 0x008E 1 word CH2 DO set/get poweron wordvalue
40144 0x008F 1 word CH3 DO set/get poweron wordvalue
40145 0x0090 1 word CH4 DO set/get poweron wordvalue
