B
B. Used Network Port Numbers
ioLogik E2200 Smart Ethernet Remote I/O
Device Network Port Usage
Port Type Usage
68 UDP BOOTPC
68 UDP DHCP
69 UDP Export/import file
80 TCP Web Server
161 TCP SNMP
502 TCP Modbus Communication
4800 UDP Auto search
9020 TCP Peer-to-Peer function
9000 TCP Active Message (Default)
9000 UDP Active Message (Default)
9900 TCP Active Tags updates (default)
4040 TCP ioEventLog
