ioLogik E2200 Series Modbus/TCP Address Mappings
I-6
Reference Address Data Type Description
00091 0x005A 1 bit CH6 DI Trigger Status
Read: 0 : Normal
1 : Trigger
Write: 0 : Clear Trigger Status
1 : Return Illegal Data Value
00092 0x005B 1 bit CH7 DI Trigger Status
Read: 0 : Normal
1 : Trigger
Write: 0 : Clear Trigger Status
1 : Return Illegal Data Value
00093 0x005C 1 bit CH8 DI Trigger Status
Read: 0 : Normal
1 : Trigger
Write: 0 : Clear Trigger Status
1 : Return Illegal Data Value
00094 0x005D 1 bit CH9 DI Trigger Status
Read: 0 : Normal
1 : Trigger
Write: 0 : Clear Trigger Status
1 : Return Illegal Data Value
00095 0x005E 1 bit CH10 DI Trigger Status
Read: 0 : Normal
1 : Trigger
Write: 0 : Clear Trigger Status
1 : Return Illegal Data Value
00096 0x005F 1 bit CH11 DI Trigger Status
Read: 0 : Normal
1 : Trigger
Write: 0 : Clear Trigger Status
1 : Return Illegal Data Value
00097 0x0060 1 bit CH0 DI Counter Power On Status 0: Off 1: On
00098 0x0061 1 bit CH1 DI Counter Power On Status 0: Off 1: On
00099 0x0062 1 bit CH2 DI Counter Power On Status 0: Off 1: On
00100 0x0063 1 bit CH3 DI Counter Power On Status 0: Off 1: On
00101 0x0064 1 bit CH4 DI Counter Power On Status 0: Off 1: On
00102 0x0065 1 bit CH5 DI Counter Power On Status 0: Off 1: On
00103 0x0066 1 bit CH6 DI Counter Power On Status 0: Off 1: On
00104 0x0067 1 bit CH7 DI Counter Power On Status 0: Off 1: On
00105 0x0068 1 bit CH8 DI Counter Power On Status 0: Off 1: On
00106 0x0069 1 bit CH9 DI Counter Power On Status 0: Off 1: On
00107 0x006A 1 bit CH10 DI Counter Power On Status 0: Off 1: On
00108 0x006B 1 bit CH11 DI Counter Power On Status 0: Off 1: On
00109 0x006C 1 bit CH0 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
00110 0x006D 1 bit CH1 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
