ioLogik E2200 Series Modbus/TCP Address Mappings
I-52
Reference Address Data Type Description
40018 0x0011 1 word CH5 AI range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40019 0x0012 1 word CH6 AI range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40020 0x0013 1 word CH7 AI range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40021 0x0014 1 word CH0 AI power-on range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40022 0x0015 1 word CH1 AI power-on range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40023 0x0016 1 word CH2 AI power-on range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
