ioLogik E2200 Series Modbus/TCP Address Mappings
I-7
Reference Address Data Type Description
00111 0x006E 1 bit CH2 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
00112 0x006F 1 bit CH3 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
00113 0x0070 1 bit CH4 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
00114 0x0071 1 bit CH5 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
00115 0x0072 1 bit CH6 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
00116 0x0073 1 bit CH7 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
00117 0x0074 1 bit CH8 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
00118 0x0075 1 bit CH9 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
00119 0x0076 1 bit CH10 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
00120 0x0077 1 bit CH11 DI Counter Safe Mode Status
Read: 0 : Stop
1 : Start
Write: 0 : Stop
1 : Start
