ioLogik E2200 Series Modbus/TCP Address Mappings
I-59
Reference Address Data Type Description
00081 0x0050 1 bit CH8 DI Counter Status 0: Off 1: On
00082 0x0051 1 bit CH9 DI Counter Status 0: Off 1: On
00083 0x0052 1 bit CH10 DI Counter Status 0: Off 1: On
00084 0x0053 1 bit CH11 DI Counter Status 0: Off 1: On
00085 0x0054 1 bit CH0 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00086 0x0055 1 bit CH1 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00087 0x0056 1 bit CH2 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00088 0x0057 1 bit CH3 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00089 0x0058 1 bit CH4 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00090 0x0059 1 bit CH5 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00091 0x005A 1 bit CH6 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00092 0x005B 1 bit CH7 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00093 0x005C 1 bit CH8 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00094 0x005D 1 bit CH9 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00095 0x005E 1 bit CH10 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00096 0x005F 1 bit CH11 DI Clear Count Value read always: 0
Write: 1 : Clear counter value
0 : return Illegal Data Value
00097 0x0060 1 bit CH0 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
00098 0x0061 1 bit CH1 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
