ioLogik E2200 Series Modbus/TCP Address Mappings
I-25
4xxxx Read/Write Registers (Functions 3, 6, 16)
Reference Address Data Type Description
40001 0x0000 word CH0 DO pulse output count value hi-word
40002 0x0001 word CH0 DO pulse output count value lo-word
40003 0x0002 word CH1 DO pulse output count value hi-word
40004 0x0003 word CH1 DO pulse output count value lo- word
40005 0x0004 word CH2 DO pulse output count value hi- word
40006 0x0005 word CH2 DO pulse output count value lo- word
40007 0x0006 word CH3 DO pulse output count value hi- word
40008 0x0007 word CH3 DO pulse output count value lo- word
40009 0x0008 word CH4 DO pulse output count value hi- word
40010 0x0009 word CH4 DO pulse output count value lo- word
40011 0x000A word CH5 DO pulse output count value hi- word
40012 0x000B word CH5 DO pulse output count value lo- word
40013 0x000C word CH6 DO pulse output count value hi- word
40014 0x000D word CH6 DO pulse output count value lo- word
40015 0x000E word CH7 DO pulse output count value hi- word
40016 0x000F word CH7 DO pulse output count value lo- word
40017 0x0010 word CH8 DO pulse output count value hi- word
40018 0x0011 word CH8 DO pulse output count value lo- word
40019 0x0012 word CH9 DO pulse output count value hi- word
40020 0x0013 word CH9 DO pulse output count value lo- word
40021 0x0014 word CH10 DO pulse output count value hi- word
40022 0x0015 word CH10 DO pulse output count value lo- word
40023 0x0016 word CH11 DO pulse output count value hi- word
40024 0x0017 word CH11 DO pulse output count value lo- word
40025 0x0018 word CH0 DO pulse low signal width
40026 0x0019 word CH1 DO pulse low signal width
40027 0x001A word CH2 DO pulse low signal width
40028 0x001B word CH3 DO pulse low signal width
40029 0x001C word CH4 DO pulse low signal width
40030 0x001D word CH5 DO pulse low signal width
40031 0x001E word CH6 DO pulse low signal width
40032 0x001F word CH7 DO pulse low signal width
40033 0x0020 word CH8 DO pulse low signal width
40034 0x0021 word CH9 DO pulse low signal width
40035 0x0022 word CH10 DO pulse low signal width
40036 0x0023 word CH11 DO pulse low signal width
40037 0x0024 word CH0 DO pulse high signal width
40038 0x0025 word CH1 DO pulse high signal width
40039 0x0026 word CH2 DO pulse high signal width
40040 0x0027 word CH3 DO pulse high signal width
40041 0x0028 word CH4 DO pulse high signal width
40042 0x0029 word CH5 DO pulse high signal width
40043 0x002A word CH6 DO pulse high signal width
40044 0x002B word CH7 DO pulse high signal width
40045 0x002C word CH8 DO pulse high signal width
40046 0x002D word CH9 DO pulse high signal width
40047 0x002E word CH10 DO pulse high signal width
40048 0x002F word CH11 DO pulse high signal width
